MM-3301HVXpert M1-HV Mini Size Full Aluminum (Xpert)

Description

MM-3301HV Xpert M1-HV Mini Size Full Aluminum

The Xpert RC M1 is an unbelievably powerful high voltage, brushless mini cyclic servo. Featuring a full aluminum case design, 4096 resolution, and impressive 198.48 oz-in & 0.06 sec/60 degrees specs at 8V, these mini servos are in a class above the competition by far.

Features:Brushless motor design provides extremely high speed, top efficiency, and low power consumption.4096 resolution and SIC (Single Integrated Circuit) for the highest performance and durability.Light weight designAll Aluminum case for the best thermal dissipation and durability.Strong Metal GearGlitch-freeSophisticated error correctionHigh-Speed, High-precision 12-bit AD converter and CPU calculationFail safeOver current protectionOver temperature protectionStart sonorantOperating frequency up to 333Hz

Specifications:Dimensions: 33.6x15x29.5mmWeight: 40.5 gSpeed:@6.0V: .084 sec/[email protected]: .068 sec/[email protected]: .06 sec/60Torque:@6.0V: 141.85 oz-in (21.43 kg-cm)@7.4V: 174.89 oz-in (26.43 kg-cm)@8.4V: 198.48 oz-in (30.00 kg-cm)
